If you are building a new home or rehabilitating one, now is the time to put in a re-circulating loop! You will have no trouble installing the return loop lines and insulating
all of the necessary pipes.
It is not hard to install hot water circulation loop In fact, over half of the work is already done as the plumber
installs water supply lines to each fixture group in your new home.
All a plumber has to do is install a 3/4 inch diameter line from the water heater that feeds all of the fixtures in the house
that need hot water. He continues this 3/4 inch pipe throughout the entire house and branches off of it to feed hot water to each fixture.
But when he gets to the farthest fixture away from the water heater, he doesn't stop the line - as most plumbers do. Instead, he continues the 3/4 inch line all the way back to the water heater without interruption.
A circulator pump is a specific type of pump used to circulate gases, liquids, or slurries in a closed circuit. They are commonly found circulating water in a hydronic heating or
cooling system. Because they only circulate liquid within a closed circuit, they only need to
overcome the friction of a piping system (as opposed to lifting a fluid from a point of lower potential energy to a point of higher potential energy).
Circulator pumps as used in hydronic systems are usually electrically powered centrifugal pumps. As used in homes, they are often small,
sealed, and rated at a fraction of a horsepower, but in commercial applications they range in size up to many horsepower and the electric motor
is usually separated from the pump body by some form of mechanical coupling. The sealed units used in home applications often have the motor rotor,
pump impeller, and support bearings combined and sealed within the water circuit. This avoids one of the principal challenges faced by the larger, two-part pumps:
maintaining a water-tight seal at the point where the pump drive shaft enters the pump body.
Small- to medium-sized circulator pumps are usually supported entirely by the pipe flanges that join them to the rest of the hydronic plumbing. Large pumps are usually pad-mounted.
Pumps that are used solely for closed hydronic systems can be made with cast iron components as the water in the loop will either become de-oxygenated or be treated with chemicals to
inhibit corrosion. But pumps that have a steady stream of oxygenated, potable water flowing through them must be made of more expensive materials such as bronze.
